The topology technology of non-isolated grid-connected photovoltaic inverters, aiming to address the issues of leakage current and improve the performance and reliability of the photovoltaic inverters. The research is of great significance as it contributes to the efficient and safe utilization of solar energy.
1. Introduction
Non-isolated grid-connected photovoltaic inverters offer advantages such as high conversion efficiency, compact size, and low cost, making them an attractive option for PV systems. However, the elimination of the transformer in these photovoltaic inverters leads to the possibility of increased leakage current, which poses a safety hazard. Therefore, studying the common-mode equivalent circuit and eliminating the switching frequency common-mode voltage is crucial for the widespread application of non-isolated inverters.
2. Leakage Current Analysis Model of Single-phase Grid-connected Photovoltaic Inverters
- High-frequency Common-mode Equivalent Model: A more comprehensive common-mode analysis model is established for single-phase non-isolated bridge grid-connected photovoltaic inverters, taking into account the influence of various parasitic parameters. These parameters include the parasitic capacitance of the solar panel to the ground, the impedance of the transmission line, and the parasitic capacitance of the bridge arms. The model provides a more accurate representation of the actual circuit and helps in understanding the mechanisms of leakage current generation.
- Elimination of Leakage Current: Based on the analysis model, two ways to eliminate leakage current are identified: 1) In the case of matching circuits and parasitic parameters symmetry, the vCM voltage generated by the SPWM switching mode is a constant value, which can effectively reduce the leakage current. 2) By circuit parameter matching, vCM + vCM-DM = const can be achieved, which also helps in suppressing the leakage current. These findings provide theoretical guidance for the design of non-isolated grid-connected photovoltaic inverters with low leakage current.
3. Leakage Current Suppression Technology for Full-bridge Photovoltaic Inverters
- Improved Full-bridge Circuit Topology: A new full-bridge circuit topology, oH5, is proposed by adding a bidirectional clamping branch in the H5 full-bridge photovoltaic inverter structure. This innovative design can ensure that the potential of the freewheeling circuit is at half of the battery voltage during the freewheeling stage, which not only reduces the conduction loss but also lowers the voltage stress of the high-frequency switch and the clamping switch. This leads to improved efficiency and reliability of the photovoltaic inverter.
- Comparison of Topologies: The device loss and leakage current suppression performance of several common topologies, including Heric, H6, H5, and the proposed oH5, are calculated and compared. The analysis takes into account factors such as the switching characteristics of the devices, the parasitic parameters, and the operating conditions of the photovoltaic inverter. The results show that the oH5 topology has a balanced performance in terms of efficiency and common-mode characteristics, making it a promising candidate for practical applications.
4. Leakage Current Suppression Technology for Half-bridge Photovoltaic Inverters
- Analysis of NPCTLI Topology: The diode-clamped three-level converter (NPCTLI) is widely used in single-phase non-isolated grid-connected photovoltaic inverters due to its advantages in compensating for leakage current and the DC component in the grid-connected current. However, the parasitic capacitance of the switch bridge and the capacitor bridge in NPCTLI may affect its leakage current suppression performance. A detailed analysis of the NPCTLI topology is conducted to understand its operating principles and characteristics.
- Improvement Measures: Three methods to suppress the leakage current in NPCTLI by parameter matching are derived. These methods include the “filtering branch” offset method, the “parasitic branch” offset method, and the “full offset” method. The full offset method is experimentally verified to be effective in enhancing the leakage current suppression performance. The implementation of these methods requires careful consideration of the circuit parameters and the operating conditions.
5. High-reliability and Low-leakage Non-isolated PV Grid-connected Photovoltaic Inverter
- SI – NPCTLI Inverter Topology: A split-inductor neutral point clamped three-level photovoltaic inverter (SI – NPCTLI) is proposed, which combines the advantages of low device voltage stress and constant common-mode voltage of the traditional neutral point clamped three-level photovoltaic inverter with the anti-through structure of the dual buck half-bridge photovoltaic inverter. This unique combination makes the SI – NPCTLI photovoltaic inverter suitable for applications requiring high reliability and low leakage current.
- Control Strategy and Simulation Results: The control strategy of SI – NPCTLI is introduced, which includes the control of the photovoltaic inverter side inductance current for unit power factor operation and the use of hysteresis current control for the grid-connected current. Simulation results show that the photovoltaic inverter has good steady-state and dynamic performance, and can effectively suppress the leakage current. The simulation also provides insights into the performance of photovoltaic inverter under different operating conditions and helps in optimizing the design.
6. Conclusion
This chapter systematically studies the leakage current suppression technology of non-isolated PV grid-connected inverters, proposes new topologies and compensation methods, and improves the reliability of photovoltaic inverters. These research results have important implications for the application of non-isolated photovoltaic inverters in PV systems. They provide valuable guidance for the design and optimization of non-isolated grid-connected photovoltaic inverters, contributing to the development of more efficient and reliable PV power generation systems.
