Introduces a distributed power supply system based on direct current (DC) – the DC microgrid – which aims to improve the efficiency of photovoltaic (PV) power utilization. The DC microgrid integrates various distributed power sources, solar energy storage devices, and loads, and can operate in both grid-connected and island modes, providing high-quality and reliable power supply.
1. Introduction
The existing PV grid-connected system has limitations such as low utilization of PV cells and excessive power conversion stages. The DC microgrid, on the other hand, can directly use the DC output of PV cells and other renewable solar energy sources, reducing the number of power conversions and losses. Additionally, it can operate in island mode, making full use of the power generated by PV cells and providing uninterrupted power supply.
2. DC Power Supply System
- Existing DC Microgrid Architectures: Several existing DC microgrid architectures are introduced, including the system proposed by ABB and the systems developed by CPES and the Korean Smart Microgrid Research Center. These architectures typically include components such as a DC bus, bidirectional AC/DC converters, solar energy storage devices, and various distributed power sources.
- Proposed System Architecture: The proposed DC microgrid system in this chapter includes a 380V DC bus connected to the main grid through a bidirectional AC/DC converter, a 48V DC bus supported by a low-voltage battery and connected to the 380V bus through an isolated bidirectional DC/DC converter, and a supercapacitor connected to the 380V bus through a non-isolated bidirectional DC/DC converter. The system also integrates PV cells, wind turbines, and fuel cells as power sources.
3. Interface Units in the DC Microgrid
- DC Microgrid-Grid Interface Unit: The bidirectional AC/DC converter is used as the interface between the DC microgrid and the main grid. Multiple converters with different power capacities are used to optimize efficiency and reduce standby losses. The control strategy of the converter includes a double-loop structure with the DC bus voltage as the outer loop and the grid-side current as the inner loop.
- DC Microgrid-Energy Storage Interface Unit: The non-isolated multi-channel bidirectional DC/DC converter is used as the interface between the DC microgrid and the solar energy storage device. The converter adopts a control strategy that regulates the DC bus voltage on the high-voltage side and the current of the supercapacitor on the low-voltage side, enabling free bidirectional power flow.
- DC Microgrid-Dual DC Bus Interface Unit: The interface between the 380V and 48V DC buses in the DC microgrid is realized through an isolated bidirectional DC/DC converter. The proposed converter structure consists of a current-source half-bridge on the low-voltage battery side and a voltage-source half-bridge on the 380V DC bus side, forming a completely symmetrical and complementary combination. An active clamping network is added to the current-source side to achieve zero-voltage switching (ZVS) and eliminate voltage spikes. Phase-shift and PWM control are used to match the voltages at both ends of the transformer during voltage fluctuations.
- PV-DC Bus Interface Unit: The interface between the PV cells and the DC bus in the DC microgrid is achieved through a non-isolated DC/DC converter, such as the double-tube Buck-Boost converter. To reduce the reverse recovery problem and switching loss of the converter, an additional winding and two auxiliary diodes are added to the circuit.
4. Research Content and Planning
- DC Microgrid Demonstration Platform Construction: The construction of a 50kW DC microgrid power supply system is planned, including the integration of various power units and the development of a monitoring and protection system.
- DC Microgrid Technology Research: The research includes the coordination control of distributed power sources in the DC microgrid, the economic operation theory and solar energy optimization management method, the development of efficient user power converters in the DC power supply environment, the monitoring and protection of the DC microgrid system, solar energy storage unit and electric vehicle charging management, and the LED efficient driving technology for the lighting system.
5. Conclusion
This chapter presents a DC microgrid system architecture and the selection of interface circuits, including the bidirectional AC/DC converter, the non-isolated bidirectional DC/DC converter, the isolated bidirectional DC/DC converter, and the non-isolated DC/DC converter for the PV interface. The proposed system architecture and interface circuits lay the foundation for the construction and research of the DC microgrid.
